48mm Single Sided Masking Polyimide Adhesive Tape Customized

Place of Origin CHINA
Brand Name UNIFORM
Certification RoHS, ISO9001, CE, TUV
Model Number AUTC-PAT-558
Minimum Order Quantity 50,000rolls
Price Negotiable
Packaging Details carton box and wooden box
Delivery Time 10-12days
Payment Terms T/T, Western Union
Supply Ability 5000,000rolls/day
Product Details
Material Polyimide Colour Cloden
Length 33mts Or Customized Width 12/19/24/25/36/48/50mm Or Customized
Thickness 60microns -- 80microns Feature Waterproof
High Light

48mm Polyimide Adhesive Tape

,

Masking Polyimide Adhesive Tape

,

48mm polyimide masking tape

Leave a Message
Product Description

High Temperature Heat Resistant Polyimide Film Single Sided Adhesive Tape



Feature
  • Thin backing leaves a sharp paint line
  • Silicone adhesive offer high heat resistance,reducing failure due to softening,oozing and adhesive transfer.
  • Silicone adhesive remove cleanly without glue residue
  • Polyimide film offer excellent thermal,abrasion and chemical resistance while maintaining their flexibility.
  • Amber color makes tape placement obvious for both application and removal


Description
The Item Is A Simple And Practical Tape, Which Is Mainly Made Of Durable Polyimide And Silicone Materials, And Features One-Side Self-Adhesive Design For Easy To Use. It Is Highly Resistant To Heat And Chemicals, Puncture And Tear Resistant At High Temperatures And Offers Optimal Performance In Electrical And Thermal Insulation, And So It Is Widely Used As Electrical Insulation Transformer, Motor, Coil, Capacitor And Frequency Conversion Power Supply In Electronic Industry.





Application
·It can endure high temperature up to 260 °C within half an hour.
·electrical insulation, radiation resistance, solvement resistance ,heat resistance,etc.
·Its mostly applied for the motor insulation, protection of PCB during wave soldering etc.
Without any residue after the tape is removed from the gold finger.

Details

Backing
0.075mm Polyimide film
Adhesion
Silicone
Color
Amber
Thickness (mm)
0.11
Width(mm)
500mm
Length (m)
33M
Tensile Strength (N/25mm)
≥160
Elongation (%)
≥60
Breakdown strength (N/25mm)
≥200
Voltage resistance (KV)
12
Adhesion (N/25mm)
≥6
Temperature Resistance (℃)
260℃
